The ARCAM A25+ is the best sounding, and most versatile of our Radia+ integrated amplifiers.
Couldn't load pickup availability
Description
Description
The "A" in ARCAM stands for amplification, where their expertise lies. The A25+ is the latest in nearly 50 years of amplifier design and manufacture, dating back to their first product in 1976 —the A&R Cambridge A60 amplifier. Since the launch of the award-winning ARCAM Radia A25, they haven't rested. Arcam's engineering team pushed further to create the ARCAM A25+, an even better sounding and more versatile integrated amplifier.
With a wide array of analogue inputs, including a meticulously tuned phono stage, and digital inputs including HDMI eARC and USB-C, the A25+ provides an impact for everything from vinyl to TV and Streaming.
The A25+ features an enhanced power supply design, new DAC and cutting-edge wireless capabilities straight out of the box. Snapdragon Sound delivers uncompressed digital audio via Bluetooth, while Auracast enables multiple compatible headphones or speakers to share music wirelessly, with no pairing required. Powered by 5th generation Class G amplifier design, you can expect the best sound quality and dynamics from what has always been a better sounding, and more efficient Class of amplifier.
- ARCAM Class G amplification - for ultra-low distortion
-
2x 100W Power Output - powers loudspeakers effortlessly.
-
Wireless audio with Snapdragon Sound and Auracast built-in - for the best sound with the most convenience
-
Wired or Wireless Headphones - connect your headphones for quiet listening with, or without wires
-
HDMI eARC/ARC input
-
USB-C input
-
Fine-tuned phono stage - ensures your records sound as detailed and engaging as possible
-
Plastic Free Packaging - for easy disposal of natural materials
Specifications
Specifications
Continuous power output (0.5% THD), per channel
- 2 channels driven, 20Hz - 20kHz, 8ohms 100W
- 2 channels driven, 1kHz, 4ohms 165W
- Harmonic distortion, 80% power, 8ohms at 1kHz 0.002%
Analogue Inputs
- Number of inputs 3 (RCA pairs)
- Signal/noise ratio (A-wtd, ref. 50W, 1V input) 106dB
- Frequency response 20Hz—20kHz ± 0.2dB
Phono (MM) Input
- Input impedance 47kohms + 100pF
- Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB
Digital Inputs
- Supported Sample Rates (kHz)
- USB-C Only 384, 352.8, 192, 176.4, 96, 88.2, 48, 44.1
- Other digital inputs 192, 176.4, 96, 88.2, 48, 44.1
- Bit depths (bit) 32, 24, 16
- Frequency response (filter 1) 20Hz—20kHz ± 0.2dB
- Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 109dB
Headphone Output
- Maximum output level (RMS) into 32ohms/300ohms 2.5V/5V
- Load range 16ohms - 2kohms
Wireless Specifications
Bluetooth Version - 5.4; A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD and aptX Lossless, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power - 2,400 MHz to 2,483.5 MHz: <20dBm
General
- Mains voltage 100V or 110–120V or 220–240V, 50–60Hz
- Power consumption (maximum) 500W
- Power consumption (standby) <0.5W
- Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 83mm
- Weight (net) 9kg
- Weight (packed) 12kg
Supplied accessories
- Mains lead(s)
- Remote control with 2 x AAA batteries
- Quick Start Guide
- Important Safety Instructions
5 Year Warranty
5 Year Warranty
The warranty period starts from the date of purchase and covers you from manufacturing defects & unexpected faults through normal use. It does NOT cover you from accidental damage, damage caused by usage outside of product specifications or expected product wear and tear.
