Bowers & Wilkins DB3D Subwoofer
Bowers & Wilkins DB3D Subwoofer
Despite its compact dimensions, DB3D delivers astonishingly powerful, controlled bass thanks to its twin 8in Aerofoil™ drivers, 1000 watt amplifier and digital signal processing.
Couldn't load pickup availability
Description
Description
More bass, less space
Compact model packs a mighty punch. Controllable, dramatic bass from a subwoofer so small it fits almost anywhere: DB3D is a space-saving high-performance design.
Nimble and powerful
Solid, dramatic bass is delivered through the rigidity and lightness of the uniquely-shaped variable thickness Aerofoil™ cone.
A question of balance
The back-to-back (opposed) drivers cancel out cabinet resonances, ensuring all that power is used to create room-shaking bass, not wasted vibrations.
The digital advantage
Digital amplification is cool-running and energy efficient, even when working hard, while Dynamic EQ and Room EQ ensure a precise sound for music and movies.
Take control
By placing control in the palm of your hand, our subwoofer app not only makes our DB Series subwoofers a snap to set up, it also helps maximise your sound quality.
Specifications
Specifications
Technical features
- 1000w Class D Hypex amplifier
- 2 x 200mm (8in) Aerofoil™ cone drive units in a balanced configuration
- Digital preamplifier with Dynamic EQ
- App-based set-up and BT-LE control
Description
DB Series subwoofer
Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø165mm (6.5 in) Continuum cone bass / midrange
Frequency range
45Hz and 33kHz
Frequency response
50Hz - 28kHz ±3dB
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 100Hz - 22kHz
<0.5% 150Hz - 20kHz
Nominal impedance
8ohms (minimum 3.7ohms)
Recommended amplifier power
30W - 120W into 8ohms on unclipped programme
Sensitivity
88dB spl (2.83Vrms, 1m)
Max recommended cable impedance
0.1ohms
Dimensions
Height: 345mm (13.6 in) cabinet only
413mm (16.3 in) including tweeter
Width: 192mm (7.6 in) cabinet only
Depth: 297mm (11.7 in) cabinet only
337mm (13.3 in) including grille and terminals
Net weight
9.58kg (21.1 lb)
Cabinet finishes
Gloss Black
Satin White
Mocha
Grille finishes
Black
Grey (Satin White only)
Awards & Reviews
Awards & Reviews
Home Cinema Choice
"Rarely have I come across a subwoofer so small and so perfectly formed, yet so able to dig deep into a soundtrack. Easy to recommend. "
BEST BUY AWARD | READ MORE
