Meridian UHD121 HDMI Processor

Meridian UHD121 HDMI Processor

The UHD121 integrates seamlessly into modern home installations, delivering Meridian’s signature sound performance from today’s TVs with ease.

£1,000.00 GBP
£1,000.00 GBP
Sale Out of Stock

Description

UHD121 connects your TV to Meridian loudspeakers via HDMI eARC, delivering both audio and volume control through one streamlined link. Supporting high-resolution audio up to 24-bit/192kHz, it ensures every soundtrack is presented with clarity, depth and richness, transforming ordinary viewing into an extraordinary listening experience.

Zone Control

Compact and discreet, the UHD121 connects directly between a TV’s HDMI eARC/ARC port and Meridian DSP loudspeakers via SpeakerLink. Fully CEC enabled, the system powers on and off with the TV, and volume is controlled from the TV’s own remote. This delivers a seamless experience: high-performance sound with simple, intuitive control — no extra remotes, no additional steps. Unlike generic eARC adapters, UHD121 is a manufacturer-engineered, audiophile-grade controller designed for integrators and the Meridian DSP ecosystem.

INPUT EXPANDER

Flexible system design - daisy-chain or star-wired SpeakerLink connections plus an additional HDMI input for direct source integration.

CONTROL ENABLER

Luxury sound, simple control - enables Meridian DSP loudspeakers to integrate directly with TVs, all controlled from the TV’s own remote.

INSTALLATION

Out-of-the-box performance - plug-and-play in most systems, minimising installer time and client training. Works with existing Meridian DSP loudspeaker systems, protecting customer investment and enabling straightforward upgrades.

Specifications

CONNECTIVITY

  • 2x Meridian SpeakerLink: Master and Slave, RJ45
  • 1 x USB- B for configuration and maintenance
  • 1 x HDMI: CEC, eARC and ARC compatible
  • 1 x HDMI input socket for additional source product
  • 1 x 12V, 5W PSU input

VIDEO CAPABILITIES

  • HDMI 1.4 & 2.0b, HDCP 2.3
  • HDR (including HDR10+)
  • 12-bit deep colour
  • Supports up to 4096 x 2160 @ 60Hz

AUDIO CAPABILITIES

  • SPDIF digital audio at 44.1kHz, 48kHz, 88,2kHz, 176.4kHz or 192kHz - all up to 24-bit
  • Encoded Dolby Digital and DTS passthrough (no decoding)

CONTROL OPTIONS

  • CEC over HDMI
  • Meridian SpeakerLink
  • Meridian Control app via USB from Windows PC or MacOS
  • Third-party control systems using the Meridian Automation Interface

POWER OPTIONS

  • Via Master SpeakerLink socket
  • External PSU (available separately), 12V, 5W

DIMENSIONS

  • HEIGHT: 35.5mm [1.4in]
  • WIDTH:80mm [3.2in]
  • DEPTH: 170mm [6.7in]
  • WEIGHT: 0.52kg [1.1lbs]

3 Year Warranty

+ 2 Year Extended Warranty available (totalling to 5 years) when you register your product on the Meridian website.

REGISTER HERE

The warranty period starts from the date of purchase and covers you from manufacturing defects & unexpected faults through normal use. It does NOT cover you from accidental damage, damage caused by usage outside of product specifications or expected product wear and tear.

Downloads

User Manual
