Naim NVC TT Phono Stage
Naim NVC TT Phono Stage
The NVC TT is a phono preamplifier that is super simple to use. It connects easily to NAC 332 or NSC 222 preamplifiers, offering the best when listening to vinyl records, and has a dedicated power supply, NPX TT, for ultra high quality vinyl listening.
This product is only available for collection at Soundcraft
Couldn't load pickup availability
Description
Description
Get the most out of your vinyl with NVC TT. Very easy to use, it is perfectly compatible with any turntable with MC cartridges and MM cartridges, and easily connects to NAC 332 or NSC 222 preamplifiers. When linked with its dedicated power supply, NPX TT, it offers high performance.
Naim know-how
Under the leadership of our Technical Director, our engineers have developed specific electronic circuits to give the New Classic products superior performance. The best audiophile components have been chosen for NVC TT and highly precise measurements to achieve an uncompromising result. It is an innovative concept, which partly uses the association between the phono stage and the power supply like in Naim’s Solstice Special Edition.
Perfect integration in a complete system
NVC TT connects easily to preamplifiers NSC 222 and NAC 332 from the New Classic range. It has a dedicated power supply, NPX TT, for the ultimate vinyl listening experience.
A timeless design
Naim products are designed to be both contemporary and timeless. Our creations forgo any unnecessary adornments that would detract from the performance and sound quality delivered. The design of NVT TT is inspired by previous Naim creations, such as the SuperLine, but also the Statement amplifier. It is razor sharp, combining a sleek design, premium materials and adjustable logo brightness.
The story of Naim and aluminium
Our founder, Julian Vereker, immediately understood the many benefits of aluminium for wrapping Naim electronic components. He knew that delicate audio components are very sensitive to the effects of magnetic fields, thermal instability, unwanted vibrations, etc.
The New Classic range maximises this highly technical and durable approach, with aluminium housings rivalled only by Statement, our flagship product. Naim chose a superior-quality aluminium, which optimally combines thermal and microphonic properties. The front panels are treated with solid 20mm-thick aluminium billets; heat sinks frame the side panels and 5mm plates cover the top and bottom surfaces of the products. The aluminium is brushed, sandblasted and anodised to guarantee unalterable beauty throughout the product's life. The New Classic range can be immediately distinguished with one look and one touch, before the first note of music even plays.
Specifications
Specifications
- Product Type
Switchable MM/MC phono stage with MC load adjustment - Audio Outputs
Max output signal: 8 Vrms - Headroom:
MM: 22dB ref 5mV input
MC (low & high gain): 23dB ref 0.5mV input low gain setting, 17dB ref 0.5mV high gain setting - Audio Inputs
MM: (Partial) – 2dB at 20Hz and -3dB at 14Hz
Audio Inputs
- Power Amp In
+/-18V DC @300mA
Audio Outputs
- Powered Accessory Sockets
Stereo RCA - Crosstalk
MM: >75dB - THD + N
MM: <0.005% ref 50mV input
MC (low & high gain): <0.005% ref 1.5mV inpu - Signal-to-Noise Ratio
MM: 83dB réf. 5 mV A-wtd
MC (low & high gain): 84dB ref 0.5mV A-wtd (both gain settings) - Gain
MM: 42dB
MC (low & high gain): 61dB low gain and 67dB high gain (switchable)
Phono Specific
- RIAA Accuracy
MM: +/-0.1dB
Physical
- Weight
7.5lbs (3.4kg) - Dimensions (HxWxD)
2 3/4x 8 3/8x 12 1/2" (7x21.4x31.7cm)
Power
- Amplifier Output
1 x Stereo RCA
1 x 5 pin DIN
1 x 8 pin DIN - Power Output
MM: 47kohms and 100pF
MC (low & high gain):
16 selectable resistive values:
1 000ohms, 600ohms, 430ohms, 330ohms, 250ohms,
215ohms, 185ohms,165ohms,150ohms, 140ohms, 125ohms,
115ohms, 105ohms, 100ohms, 90ohms, 85ohms
16 selectable capacitive values:
100 pF, 400 pF, 700 pF, 1000 pF,
1300 pF, 1600 pF, 1900 pF, 2200 pF,
2500 pF, 2700 pF, 3100 pF, 3400 pF,
3700 pF, 4000 pF, 4300 pF, 4600 pF
