Rotel RAS-5000 Streaming Integrated Amplifier
Rotel RAS-5000 Streaming Integrated Amplifier
Simplicity and performance meet in the Rotel RAS-5000, a component designed to fit into your lifestyle and elevate your entertainment experience.
Couldn't load pickup availability
Description
Description
Simplicity and performance meet in the Rotel RAS-5000, a component designed to fit into your lifestyle and elevate your entertainment experience.
- 2 x 220 Watts of robust Class AB power, 4 Ohms
- Class AB amplifier design
- ESS premium 32-bit Digital to Analog Converter
- Wireless aptX™ HD and AAC Bluetooth
- Includes remote control
Simplicity and performance meet in the Rotel RAS-5000 designed to effortlessly fit into your lifestyle and elevate your entertainment experience. Stream your favorite music from Spotify Connect, Tidal Connect, Internet Radio, or any service available on your computer, tablet, or mobile device via Airplay 2, Google Cast, Roon, or aptX™ HD Bluetooth.
The HDMI ARC (Audio Return Channel) connection ensures dynamic, high resolution sound for your favorite live sports, TV shows, movies, and games directly from your TV powering 220 watts of Class AB output into 4 ohms.
Enhance and simplify your home entertainment experience without compromise today with the Rotel RAS-5000 and immerse yourself in sound.
Specifications
Specifications
DIMENSIONS (W × H × D)
431 x 144 x 425 mm
17” x 5 7/8” x 16”
FRONT PANEL HEIGHT
132.6 mm / 5 1/4”
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
380W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
15.7 kg, 34.6 lbs
BTU RATING (4ohms, 1/8th power)
1027 BTU/h
POWER OUTPUT
220 Watts / ch (4 Ohms)
140 Watts / ch (8 Ohms)
TOTAL HARMONIC DISTORTION(THD)
<0.03%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz, ±0.5dB
Digital Inputs: 10 Hz – 70k Hz, (±3 dB, MAX)
S/N RATIO (IHF "A" Weighted)
Line Level Inputs: 103dB
Digital Inputs: 105dB
INTERMODULATION DISTORTION (60 Hz : 7k Hz, 4:1)
<0.03%
DAMPING FACTOR
290
INPUT SENSITIVITY
Line Level Inputs: 0.78V
Digital Inputs: -8dBfs
INPUT IMPEDANCE
Line Level Inputs:46k Ohms
Digital Inputs: 75 Ohms
INPUT OVERLOAD
Line Level Inputs: 4.1V
TONE CONTROLS
±10dB at 100Hz / 10kHz
HDMI
Support eARC function
COAX/OPTICAL DIGITAL INPUT SIGNALS
SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 2.0 (up to 24-bit/384kHz)*
*Driver installation required
MQA and MQA Studio (up to 24-bit/384kHz )
Roon Ready
