Rotel T11 DAB & FM Tuner
Rotel T11 DAB & FM Tuner
Rotel’s T11 is a high quality FM/DAB+ tuner with up to 30 station presets. It provides a wealth of free music listening options.
Couldn't load pickup availability
Description
Description
Rotel’s T11 is a high quality FM/DAB+ tuner with up to 30 station presets. It provides a wealth of free music listening options.
- DAB+ tuning
- RDS (Radio Data System) capability for FM broadcasts
- Includes remote control
Rotel has been producing quality tuners since the 1960s. One of the latest additions to this long-established line-up is the T11 FM/DAB+ tuner. It provides a wealth of listening options with easy access to classic analogue FM stations as well as newer DAB+ (Digital Audio Broadcasting) services.
Like the T14, T11 features the ability to easily store and recall up to 30 presets each for FM or DAB+ stations. A further useful feature common to all 14 Series products is the ability to dim the display panel and power LED to provide a comfortable visual reference in all lighting environments.
Specifications
Specifications
DIMENSIONS (W × H × D)
430 × 73 × 330mm
17" × 2.9" × 13"
FRONT PANEL HEIGHT
60mm (2.36")
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
10W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
4.3kg (9lbs.)
BTU RATING
17 BTU/h
DAB SENSITIVITY
-80dBm
DAB TUNING RANGE
Band III (174-240MHz)
DAB AUDIO DATE RATE
224Kbps Max
DAB FREQUENCY RESPONSE
20Hz - 20kHz ±1dB
DAB ANALOG OUTPUT
2.1V at 0dBfs
DAB ANTENNA INPUT
75ohms F Connector
FM USABLE SENSITIVITY
22.2dBf
FM 50DB QUIETING SENSITIVITY
27.2dBf (Mono)
FM SIGNAL TO NOISE RATIO (at 65dBf)
63dBf (Mono)
60dBf (Stereo)
FM HARMONIC DISTORTION (at 65dBf)
0.2% (Mono)
0.3% (Stereo)
FM FREQUENCY RESPONSE
10Hz - 15kHz ±3dB
FM STEREO SEPARATION (100Hz/1kHz)
40dB/37dB
FM OUTPUT LEVEL
1V
FM ANTENNA INPUT
75ohms F Connector
